С 135 CЅ - С 135 AGP Modulated Gas Burners
High efficiency, durable, long-life design with wide modulated operating range.
For delivery schedule and order, please contact our sales supervisor via our e-mail address
info@gokceburner.com.
| BURNER TYPE |
C 135 cS (ORS) |
| RELAY |
SIEMENS LME 22 |
| FLAME DETECTOR |
IONANIZATION ELECTRODE |
| FAN MOTOR |
2,2 kW, 2800 d/d |
| ELECTRICAL PANEL |
ON THE BURNER |
| TRANSFORMER |
SEK. 2x5000V |
| SERVOMOTOR |
SIEMENS SQN 31.481 |
| FAN |
D 250 x 80mm d = 24mm |
| GAS LINE 21 mbar |
SIEMENS VGD 20.5011 - SKP 75 - SKP 15 (FILTRE 2") |
| GAS LINE 300 mbar |
SIEMENS VGG 10.254 - SKP 75 - DUNGS MVD 510 (FILTRE 1") |
| GAS LEAKAGE CONTROL |
- |
